Description of the System Zoom90 | 19

Container for instru-

ment and accessories

part 2 of 2

2.4 Instrument Components

Instrument components

part 1 of 2

a) Spare stylus*

b) Quick Guide, CD

c) SD card

d) Battery charger

e) Car adapter power plug for battery charger (stored under battery charger)

*optional

009834_001

a) Carry handle

b) Optical sight

c) Telescope, integrating EDM, AiM, NavLight,

Scout

d) NavLight flashing diode - yellow and red

e) Scout, transmitter

f) Scout, receiver

g) Coaxial optics for angle and distance measure-

ment, and exit port of visible laser beam for

distance measurements

h) Communication side cover

i) Horizontal drive

j) Tribrach securing screw

a b

h i

c fed g

009835_001
