Zoom90 | 24Operation
4 Operation
4.1 Main Menu
Description The MAIN MENU is the starting place for accessing most functionality of the instrument. It is displayed
when selecting the Zoom90 basic application from the WinCE main screen.
MAIN MENU
Description of the MAIN MENU functions
4.2 System Information
Description The SYSINFO screen display instrument, system and firmware information, as well as date and time.
Access Select Sysinfo from the MAIN MENU.
SYSINFO This screen displays information about the instrument and operating system.
System information Page 1
Page 2
Page 2 displays several version numbers of software and hardware components.
Function Description
1 Level To select and open Level Up screen. Refer to " Level up with the electronic level step-
by-step".
2 Sysinfo To select and start Sysinfo. Refer to "4.2 System Information".
3 Settings To select and start Settings. Refer to "5 Settings".
4 Apps To select and start Apps. Refer to Apps
LEGAL
To display legal info according open source soft-
ware.
Field Description
Instrument Model Displays the type name of the instrument.
Serial Number Displays the serial number of instrument.
Equipment Number Displays the equipment number of instrument.
Angle Accuracy Displays the accuracy of angle measurement.
EDM Displays the type of EDM.
To Next Page
