Zoom90 | 48Technical Data
Maximum speed in
TRack mode
Searching
Characteristics
8.6 Prism Search (Scout)
Range
Measurements at the vertical limits of the fan or under unfavourable atmospheric conditions may reduce
the maximum range. (*optimally aligned to the instrument)
Searching
Characteristics
8.7 Conformity to National Regulations
8.7.1 Zoom90
Conformity to national
regulations
Frequency band 2402 - 2480 MHz
Output power
Antenna
Maximum tangential speed: 5 m/s at 20 m; 25 m/s at 100 m
Maximum radial speed with Measure mode: Contin-
uous
5 m/s
Typical search time in field of view: 1.5 s
Field of view: 1°25’/1.55 gon
Definable search windows: Yes
Principle: Digital image processing
Type: Infrared laser
Reflector Range PS
[m] [ft]
Standard prism (ZPR100) 300 1000
360° prism (ZPR1, GRZ122) 300* 1000*
360° mini prism (GRZ101) Not recommended
Mini prism (ZMP100) 100 330
Shortest measuring distance: 1.5 m
Typical search time: <10 s
Default search area: Hz: 400 gon, V: 40 gon
Definable search windows: Yes
Principle: Digital signal processing
Type: Infrared laser
• FCC Part 15 (applicable in US)
• Hereby, GeoMax AG, declares that the Zoom90 is in compliance with the essential requirements and
other relevant provisions of Directive 1999/5/EC. The declaration of conformity is available from
http://www.geomax-positioning.com/Downloads.htm.
Class 1 equipment according European Directive 1999/5/EC (R&TTE) can be placed on
the market and be put into service without restrictions in any EEA member state.
• The conformity for countries with other national regulations not covered by the FCC part 15 or Euro-
pean directive 1999/5/EC has to be approved prior to use and operation.
• Japanese Radio Law and Japanese Telecommunications Business Law Compliance.
– This device is granted pursuant to the Japanese Radio Law and the Japanese Telecommunications
Business Law.
– This device should not be modified (otherwise the granted designation number will become
invalid).
Bluetooth:
4 mW max.
Type: Internal Microstrip antenna
Gain: 1.5 dBi
