GeoVision GV-VS14 User Manual

CMS Configurations
135
8
8.3 Dispatch Server
The Dispatch Server minimizes overloading of Center V2 Servers by re-distributing GV-
Video Server subscribers to the least busy Center V2 server.
GV-Video Server
GV-Video Server
TCP/ IP
X 4
X 4
Video Data
X 4
X 4
Center V2
Center V2
Dispatch Server
Text Data
Figure 8-6
¾ To set the appropriate port connecting to the GV-Video Server, click the Server
Setting button on the toolbar, and enable Allow GV IP devices to login as
subscriber from port. Keep the default port 5551, or modify it to match the Center
V2 port on the GV-Video Server.
Figure 8-7
For further information on how to mange the received video from the GV-Video Server, see
GV-CMS Series User’s manual.

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
