GeoVision GV-VS14 User Manual

10.5.2 Accessing Live View
You can press the Menu button on the mobile phone to see or hide the connection
information.
Motion Detected
I/O Triggered
Motion Detected
Figure 10-31
The following function buttons are available:
Icon Name Function
Channel
number
Switches to a different channel. You can drag across
the numbers to see more channels. This function is
only supported by GV-Video Server and GV-Compact
DVR.
Snapshot Saves the current image in the mobile device
Dual Stream Switches between the video streams if the GV-IP
device supports dual streams.
Screen division Displays up to four channels on the same page if the
GV-IP device supports multiple channels. This
function is only supported by GV-Video Server and
GV-Compact DVR.
164

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
