GeoVision GV-VS14 User Manual

Chapter 1 Introduction
The GV-Video Server, including the models GV-VS04H, GV-VS11, GV-VS12 and GV-
VS14, allows the conversion of any analog camera into a fully functional IP camera. It
streams the real-time digital video over the Internet in the same way that current IP
cameras do. With the analog cameras attached to the GV-Video Server, you can see
camera images through a Web browser anytime and anywhere. And with the GV-Video
Server connected to the GV-System, your existing surveillance system can be upgraded
and networked into a new IP surveillance system.
1.1 Models
The GV-Video Server has the following models:
GV-VS04H
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at the D1 resolution
- H.264 video compression
- Two-way audio
- GPS tracking / Wiegand access control support
GV-VS11
- 1-channel video input
- Records up to 30 (NTSC) / 25 (PAL) fps at the D1 resolution
- H.264, MEPG4 and MJPEG video compression
- One-way audio
- Dual streams
GV-VS12
- 2-channel video inputs
- Records up to 60 (NTSC) / 50 (PAL) fps at the D1 resolution
- MEPG4, MJPEG and H.264 video compression
- Two-way audio
- GPS tracking support
GV-VS14
- 4-channel video inputs
- Records up to120 (NTSC) / 100 (PAL) fps at the D1 resolution
- H.264 and MJPEG video compression
- Two-way audio
- GPS tracking / Wiegand access control support
- Dual Streams

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
