GeoVision GV-VS14 User Manual

10.4 3G Mobile Phone
Without installing any GV applications, you can use a 3G mobile phone to access GV-
Video Server directly.
10.4.1 Activating the 3G Mobile Phone Function
To allow remote access to the GV-Video Server, first you must select 3GPPv7,
MSViewV2/V3, SSViewV3 and GViewV2 as the connection type in the Connection
Template field on the Video Setting page, and then enable the 3GPP Server on GV-IP
Speed Dome. See 4.1.2 Video Settings and 4.3.9 3GPP/RTSP for details.
10.4.2 Connecting to the GV-Video Server
1. Open the Internet browser in the mobile phone, and enter the IP address of your GV-
Video Server. This login screen appears.
Figure 10-22
2. Enter a user name, a password, and select 3G. Then click Submit to connect.
158

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
