GeoVision GV-VS14 User Manual

Mobile Phone Connection
10
10.6.1 Connecting to GV-Video Server
To connect your iPhone, iPod Touch or iPad to the GV-Video Server, follow these steps:
1. Tap the GV-Eye icon
on the desktop of your phone. The welcome page appears.
2. Tap the Add button
. This page appears.
Figure 10-33
3. Enter the Host name, Domain/IP address, port number (default value is 10000),
username and password to log in to the GV-Video Server.
4. Tap the Save button. The GV-Video Server is now added to the IPCam list and will be
available the next time you access GV-Eye. You can tap the Edit button and then select
an Video Server to edit existing device login information.
Figure 10-34
167

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
