Preface
Welcome to the GV-Video Server User’s Manual.
The GV-Video Server has a series of models designed to meet different needs. Each
model has its own firmware that can only be used on the specific model. This Manual is
designed for the following models and firmware version:
Model Firmware Version
GV-VS04H 1.08
GV-VS11 1.03
GV-VS12 1.07
GV-VS14 1.01
IMPORTANT: For better recording efficiency and stability of GV-Video Server, after
upgrading the firmware to the above version, it is required to format the storage device
for better recording efficiency and stability. To format the storage device, be sure to back
up the data first and see 4.8.3 Storage Settings for how to format the storage device.
i

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
