GeoVision GV-VS14 User Manual

Comparison Table for Major Functions
The options or functions on the left menu of the Web interface (Figure 4-1) may vary
depended on models. The table below provides the information of major differences in
supported functions.
Model
Function
GV-VS04H
(Firmware
V1.03 or later)
GV-VS11
(Firmware V1.0
or later)
GV-VS12
(Firmware
V1.02 or later)
GV-VS14
(Firmware V1.0
or later)
Dual Streams
No Yes No Yes
Wiegand
Yes
No No Yes
Buzzer
Yes
No No No
Multicast
Yes Yes Yes Yes
Tampering Alarm
Yes Yes Yes Yes
Watermark
Yes Yes Yes Yes
Text Overlay
Yes Yes Yes Yes
Video Channel
Source Settings
Yes
No No No
System Log
Yes Yes Yes Yes
GV-Backup Center
Connection
Yes Yes Yes Yes
GV-Video Gateway
Connection
Yes Yes Yes Yes
GV-GIS Connection
Yes
No Yes Yes
32

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
