GeoVision GV-VS14 User Manual

Administrator Mode
4
[Video Server Streaming Port Settings]
The VSS port enables connecting the GV-Video Server to the GV-System. The default
setting is 10000.
[UPnP Settings]
 UPNP: UPnP (Universal Plug & Play) is a networking architecture that provides
compatibility among networking equipment, software and peripherals of the 400+
vendors that are part of the Universal Plug and Play Forum. It means that they are
listed in the network devices table for the operating system (such as Windows XP)
supported by this function. Enabling this function, you can connect to the GV-Video
Server directly by clicking on the GV-Video Server listed in the network devices table.
 DLNA: allows the DLNA certified devices to automatically communicate with each
other once connected to the same network. The function is currently supported with
Windows Media Player for recording playback.
Note:
1. The DLNA function is only supported with Windows Media Player version 1.1 or
later. You must have installed GeoVision codec from the Software CD/DVD or
have accessed the GV-Video Server Web interface on the computer with Windows
Media Player.
2. The DLNA function does not support the connection to TV.
[QoS Settings]
The Quality of Service (QoS) is a bandwidth control mechanism that guarantees delay-
sensitive data flows such as voice and video streams, obtain a certain amount of
bandwidth to keep the streaming smooth.
To apply QoS to the GV-Video Server, all network routers must support QoS and QoS
must be enabled on these devices. To enable the QoS on the GV-Video Server, enter a
Differentiated Services Code Point (DSCP) value. This value is a field in an IP packet that
enables different levels of services for the network traffic. When the video stream from the
GV-Video Server reaches a router, the DSCP value will tell the router what service level to
be applied, e.g. the bandwidth amount. This value ranges from 0 to 63 in decimal format.
The default value is 0, meaning QoS is disabled.
81

GeoVision GV-VS14 Specifications

General

PAL resolutions	704 x 576, 704 x 576, 352 x 288, 352 x 288, 176 x 144 pixels
NTSC resolutions	704 x 480, 704 x 480, 352 x 240, 352 x 240, 176 x 112 pixels
Channels quantity	4 channels
Maximum frame rate	30 fps
Maximum video resolution	704 x 576 pixels
Video compression formats	H.264, M-JPEG
PTZ control	Yes
Compatible operating systems	Windows XP\\r Windows Vista\\r Windows 7\\r Windows 8\\r Windows Server 2008\\r Windows Server 2012
Product color	Black, White
Supported network protocols	HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, Multicast, RTSP, QoS (DSCP), SNMP
Copper ethernet cabling technology	100BASE-T, 10BASE-T
BNC input ports	4
I/O terminal ports	-
USB 2.0 ports quantity	2
Ethernet LAN (RJ-45) ports	1
Minimum system requirements	Internet Explorer 7+
Power requirements	12V, 1.35A
Operating temperature (T-T)	-20 - 55 °C
Operating relative humidity (H-H)	0 - 85 %

Weight and Dimensions

Weight	730 g
Dimensions (WxDxH)	145 x 174 x 40 mm
