18 GERBER EDGE Owner's Guide
Printing Another Sample Job
In the following sequence you will print a red and black job on white
vinyl. The plot (.PLT) file is already loaded on your system as part of
the GRAPHIX ADVANTAGE program.
To set up the job
1. Plug in and turn on the GERBER EDGE first, then the
GRAPHIX ADVANTAGE and the plotter.
Note: Use of the keypad and display are in the "Using the Keypad and
Display" paragraph in the "Mechanical Description" section of this manual.
2. The GERBER EDGE display reads:
OFFLINE
3. Press ONLINE on the GERBER EDGE keypad. The display
reads:
ONLINE
4. Double-click on the Plot icon in the GRAPHIX ADVANTAGE
program group. The Open dialog box appears.
5. Click on the C:\JOBS directory. Type JAKES.PLT in the File
Name list box of the Open dialog box.
6. Click on OK.
7. Press F7 for the Plotter Select dialog box.
8. If necessary, click on the 15-inch plotter connected to your system to
highlight and select it. Click on any other plotters to deselect them.
9. Click on GERBER EDGE to highlight and select it.
