Tablet Specifications
Parts Specifications
CPU Intel Tiger Lake i5 and i7 U series (vPro and non-vPro)
Cache: i5 8MB; i7 12MB
BIOS Insyde, Flash EEPROM, 16MB, UEFI, supporting TPM, vPro
(optional), NIST,
Absolute DDS (optional), WMI, BIOS
Diagnostic, Credential guard, Device guard, and MAC
passthrough
RAM 16/32GB DDR4, 3200MHz, SO-DIMM slot x 2
Video Controller
Intel® Iris® Xe Graphics
Units equipped with dual channel memory come with Intel®
Iris® Xe Graphics.
Display
Panel
12.5-inch (16:9) TFT LCD with PSR (Panel Self Refresh), FHD
1920 x 1080, dimmer mode, blackout mode, sunlight
readable, 1200 nits maximum brightness
Touchscreen Capacitive, 10-point
multi-touch, anti-glare Gorilla Glass
Audio Features Azalia, High Definition audio
Speaker 1.5 W x 2
Microphone
Integrated
Mass storage device 256GB/512GB/1TB SSD (solid-state drive) in a user-removable
canister, PCIe Gen3x4 interface, M.2 2280 type
Card slot Smart Card (option)
I/O ports USB 2.0 or RS-232 (option), PowerShare USB 3.2 Gen 1, USB-
C Thunderbolt 4, HDMI, combo audio (4-pole TRRS 3.5mm
type), RJ45, Docking, tri antenna passthrough
LAN Intel® i219-LM Gigabit Network Connection, 10/100/1000
Mbps Ethernet
Wireless LAN +
Bluetooth
Intel® Wi-Fi 6 AX201 + Bluetooth 5.1 combo
WWAN (option) Sierra EM7511/EM7565, 3G/4G/4.5G LTE-A
GPS (option) Internal UART
Camera Front: FHD 2MP webcam, IR sensor (option)
Rear: 8M pixel, autofocus, LED, video capture
Barcode reader
(option)
1D and 2D
