117
About Battery and External
Enclosure Replacement
Battery
The batteries of your product include two battery packs and a button cell
(or called RTC battery). All batteries are available from Getac authorized
service centers.
The battery pack is user-replaceable. Replacement instructions can be found
in “Replacing the Battery Pack” in Chapter 3.
The button cell must be replaced by Getac authorized service centers.
Visit the website at http://us.getac.com/support/support-select.html
for
authorized service center information.
External Enclosure
The external enclosure of the product can be removed using screwdrivers.
The external enclosure can then be reused or refurbished.
The enclosure consists of the DDR cover, four side covers, and the bottom
case. See below for information on how to remove the parts.
To remove the DDR cover:
1. Remove the battery packs.
2. Remove the 9 screws that secure the DDR cover to K120. Detach the
cover.
To Next Page
