13
Right-Side Components
For covers with an arrowhead icon, push the cover toward one side to unlock
and the other side to lock. The arrowhead points to the side for unlocking.
Ref Component Description
Stylus holder Holds the stylus.
NFC/RFID r
(optional)
Reads data from NFC/RFID tags.
Depending on the model, the component can be one of the
following:
None
USB 2.0 port Connects a USB device.
RS-232 serial
connector
Connects a serial device.
RJ45 connector Connects the LAN cable.
Security lock Locks the cover of the power connector.
Power
connector
Connects the AC adapter.
