29
Using the WLAN
The WLAN (Wireless Local Area Network) module supports IEEE 802.11ac,
compatible with 802.11a/b/g/n.
NOTE: Do not block the antenna area.
Turning On/Off the WLAN Radio
To turn on the WLAN radio:
1. Make sure that the Airplane mode is switched off. You can control the
Airplane mode using one of the below methods.
• Press Fn+F1.
• For Windows 10: Click Settings Network & Internet
Airplane mode. Slide the Airplane mode switch to the Off position.
2. If you have previously turned off the WLAN radio, use one of the below
methods to turn it on.
• For Windows 10: Click Settings Network & Internet Wi-Fi.
Slide the Wi-Fi switch to the On position.
• For Windows 7: Use either Windows Mobility Center or Getac Quick
Bar. To open Getac Quick Bar, right-click the Getac Utility icon on
Windows taskbar and select Quick Bar. Click the WLAN button in the
Quick Bar (an X over the button means the radio is currently off).
WLAN
main antenna
WLAN
auxiliary antenna
