Specifications A-1
Appendix A
Specifications
NOTE: Specifications are subject to change without any prior notice.
Parts Specifications
CPU Haswell Intel® Core™ i5/i7 processor
BIOS
Phoenix, Flash EEPROM, supporting UEFI, NIST,
ACPI, and TPM
RAM 4GB/8GB DDR3L 1600MHz SO-DIMM
Video Controller UMA - Intel® GT2
Display Panel
11.6-inch (16:9) TFT LCD, HD 1366x768, sunlight
readable, 800 Nits maximum brightness
Audio Features Azalia, High Definition audio
Speaker 1.5W x 2
Microphone Integrated microphone
Keyboard
Standard keys with numeric pad keys, 12 function
keys, special Fn (Function) key and Windows keys,
with water-proof membrane or backlight (option)
Pointing device ClickPad, glide touchpad with multi-touch feature
Hard disk drive 128/256 GB SSD (Solid-State Disk)
Card slots
ExpressCard/54
Smart Card
I/O ports
USB 3.0 x 2, USB 2.0, RS232, HDMI, combo audio
(4-pole TRRS 3.5mm type), RJ-45, Docking
LAN 10/100/1000 Mbps Ethernet
