Managing Power 3-7
CAUTION: To unlock or lock, always hold the battery latch itself to move it.
Never use the ribbon strip to pull the battery latch. The wrong method can
cause a broken strip or an incorrect battery pack installation.
3. Remove the battery pack out of the slot by pulling the ribbon strip.
4. Noting the orientation, insert the new battery pack all the way into the
slot.
5. Hold the battery latch and slide it toward the left to the locked position.
(Battery 1 as the example)
6. When closing the cover, push the tab downward until the cover clicks
into place and then slide the latch toward the locked position ( ).
CAUTION: Make sure the latch is correctly locked, not revealing the
underneath red part.
Correct Incorrect (revealing red part)
