Getinge FD1800 User Manual

<Doc_TEC><Doc_503712400><Rel_B><Lang_EN>
Page 18 av 64
Line Sub-
line
Parameter Basic
setting
Setting range Authoriza-
tion
Line 98: Input connections
98 01 Connection, level A 1 1-99 DE
98 02 Connection, level B 2 1-99 DE
98 03 Connection, level C 3 1-99 DE
98 04 Conn., descaler, low level 5 1-99 DE
98 05 Conn., descaler, empty 15 1-99 DE
98 06 Connection chemical agent low level 5 1-99 DE
98 07 Connection chemical agent empty 16 1-99 DE
98 08 Connection rinse-aid low level 6 1-99 DE
98 09 Connection rinse-aid empty 16 1-99 DE
98 10 Conn., process agent, low level 7 1-99 DE
98 11 Connection process agent empty 16 1-99 DE
98 12 Conn., spray agent, low level 8 1-99 DE
98 13 Connection spray agent empty 16 1-99 DE
98 14 Conn., leakage sensor 4 1-99 DE
98 16 Conn., door closed 11 1-99 DE
98 17 Connection, door open 12 1-99 DE
98 20 Safety switch door closing (FD1810) 13 1-99 DE
98 21 Pedal (FD1810) 14 1-99 DE
Line 99: Output connections
99 01 Conn., pressure pump 6 1-99 DE
99 02 Conn., steam generator 7 1-99 DE
99 03 Conn., cold water 1 1-99 DE
99 04 Conn., hot water 2 1-99 DE
99 05 Connection soft water 8 1-99 DE
99 06 PE system (rotary nozzle) 14 1-99 DE
99 07 SP system (spray nozzle) 13 1-99 DE
99 08 Extra nozzle 15 1-99 DE
99 10 Connection pump, descaler 8 1-99 DE
99 11 Connection pump chemical agent 7 1-99 DE
99 12 Connection pump rinse-aid 5 1-99 DE
99 13 Connection pump, process agent 10 1-99 DE
99 14 Connection pump spray agent 9 1-99 DE
99 15 Connection, extra element, steam
generator
12 1-99 DE
99 16 Connection, condensate cooler 3 1-99 DE
99 17 Connection, external cooling 4 1-99 DE
99 23 Connection relay corresp. to yellow LED 3 1-99 DE
99 24 Connection relay corresp. to red LED 4 1-99 DE
