Page 34 av 64
Fault statistics, lines 60 - 63
Time of fault
Line 60
Shows the number of seconds for which the program had been running when the fault
occurred.
00 - 9999 seconds
This value cannot be changed.
Instruction for last fault
Line 61
Show the program line in the relevant program where the fault occurred.
00 = Fault not in the program
01 - 9999 = Program line
This value cannot be changed.
Counter, total number of faults
Line 62
Counter for the total number of faults since the machine was installed.
00 - 9999
This value cannot be changed or zeroed.
Counters, fault codes F1 - F13
Line number 63, Sub-line numbers 01 - 13 Authorization code: CD
Each fault code has its own counter with the same sub-line number as the fault code.
Fault code Meaning
F1 Temperature sensor fault
F2 Level sensor fault, tank
F3 Level sensor fault, detergent
F4 Door logic error
F5 Logic error, machine configuration
F6 Inspection request
F7 Disinfection temperature not reached
F8 Door open/unlocked during process
F9 Setting incorrect
F10 Could not reach/maintain requested tank level
F11 Leakage
F12 Door cannot be locked
F14 Running time, door
F18 Wrong machine type
The counters can be zeroed by pressing .
