Function test, lines 80 - 83
Display test
Line 80 Authorization level: CD
Press ENTER. All LEDs light up and all segments on the display ash. The LEDs and
the display return automatically normal after a short time.
Reading inputs 1 - 14
Line 81, sub-lines 00 - 14 Authorization level: CD
All digital inputs can be read. The sub-line number corresponds to the number of the
input, as follows (connection: line 98, activation; line 96):
Input Function
01 Low level, tank
02 Intermediate level, tank
03 High level, tank
04 Leakage sensor
05 Level, descaler/chemical agent
06 Rinse-aid
07 Level spraying agent
08 Level, process agent
11 Door closed
12 Door locked
00 = Input not active
01 = Input active
