Control, outputs 1 - 12
Line 82, sub-lines 1 - 12 Authorization level: CD
Note:
For certain outputs to be activated, the door must be closed and locked.
All digital outputs can be controlled. The sub-line number corresponds to the number of
the output, as follows (connection: line 99, activation: line 97):
Output Function
01 Valve, cold water
02 Valve, hot water.
03 Valve condensate cooling/Yellow LED
04 External cooling/Red LED
05 Pump, rinse-aid
06 Main pump
07 Steam generator
08 Pump cooling/ Valve soft water
09 Spray pump
10 Pump, process agent
12 Third element
19 Door closing
20 Door opening
00 = Output not active
01 = Output active
Read temperature
Line 83
Read current temperature sensor value.
0 - 150 °C / 32 - 302 °F in one-degree steps.
This value cannot be changed.
Save config. in flash
Line 85
Saves the conguration in the ash memory.
Load config from flash
Line 86
Loads the conguration from the ash memory.
Calibrate with AD
Line 87
For calibration of temp sensor with AD converter.
Calibrate with independent AD
Line 88
For calibration of independent temp sensor with AD transformer.
