Page 38 av 64
Activation, inputs
Line number 96, Sub-line numbers 01 - 17 Authority level: CDE
This line number is used to tell the software which logical inputs are installed. Some
sub-line numbers are not included. They are reserved for future use.
For each input, specify:
00 = input not installed
01 = input installed
The sub-line numbers correspond to the following inputs:
Sub-line No Function
01 Activation, low level, tank
02 Activation intermediate level tank
03 Activation high level tank
04 Activation descaler, low level
05 Activation descaler empty
06 Activation chemical agent low level
07 Activation chemical agent empty
08 Activation rinse-aid low level
09 Activation rinse-aid empty
10 Activation, process agent, low level
11 Activation, process agent, empty
12 Activation spray agent low level
13 Activation spray agent empty
14 Activation, leakage sensor
15 Activation, door closed
16 Activation, door locked
17 Door open (FD1810)
20 Safety switch door closing (FD1810)
21 Pedal (FD1810)
