Output connections
Line 99, sub-lines 01 - 20 Authorization level: D
This line number is used to tell the software which physical outputs are connected to
each logical output.
The sub-line numbers correspond to the following logical outputs: The “Physical output”
column shows the connections set at the factory:
Sub-line No Function Physical output
01 Conn., pressure pump 6
02 Conn., steam generator 7
03 Conn., cold water 1
04 Conn., hot water 2
05 Conn., soft water 8
06 PE system (rotary nozzle) 14
07 SP system (spray nozzle) 13
08 Extra nozzle 15
10 Connection pump, descaler 8
11 Connection pump chemical agent 7
12 Connection pump rinse-aid 5
13 Connection pump, process agent 10
14 Connection pump spray agent 9
15 Connection, extra element, steam generator 12
16 Connection, condensate cooler 3
17 Connection, external cooling 4
23 Connection relay corresp. to yellow LED 3
24 Connection relay corresp. to red LED 4
