TECHNICAL DATA
GETINGE HS33
Dimensions (W x D x H)
HS33 60-liters: 595 x 880 x 1575 mm
HS33 100-liters: 595 x 1250 x 1575 mm
Chamber size (W x D x H)
HS33 60-liters: 320 x 620 x 320 mm
HS33 100-liters: 320 x 971 x 320 mm
Chamber corner radius 20 mm
Chamber volume
HS33 60-liters: 63 liters (1 STU)
HS33 100-liters: 99 liters (1.5 STU)
Chamber weight HS33 60-liters: 85 kg HS33 100-liters: 115 kg
Chamber design pressure 2,7 bars
Chamber regulations PED 2014/68/EU EN 13445, ASME VIII, JBA/MHLW
Chamber material EN 10028-7 1.4404/1.4571, AISI 316L/AISI 316Ti
Chamber temperature (TS), maximum 140 °C
Door material EN-AW 5754H111 / SB-247A92014T6
Weight of steam generator 35 kg
Loading height 900 + 0-100 mm
Maximum load (i
ncl. rack, baskets, trays etc.) 15 kg (instruments), 7,5 kg (textiles, 80 % of chamber volume)
Water connection: pressure / quality / temp.
3-6 bar / 4 dH / max 20 °C
Feed water for steam production Deionized or RO water max. 30 µS/cm
Maximum steam fl ow
420 liters/min
Tank volume 7 liters tap water, 5 liters deionized/RO water
Water consumption/process
(depending on load and process type)
HS33 60-liters: Ejector system: ~50-60 L tap water
Water saving system: ~7-15 L tap water
HS33 100-liters: ~100-120 L tap water
Water consumption during steam production Maximum 0,4 liters/min
Drain fl ow, maximum 12 liters/min
Electrical connection (max. variation)
According to rating plate
400 V~ 3N PE (±10 %) 16 A fuse
230 V~ 3 PE (±10 %) 16 A fuse
208 V~ 3 PE (±10 %) 16 A fuse
Electrical consumption, average load 1,75 kWh
Electrical consumption, stand-by 0,77 kWh
Effect, total 5 500 W
Effect, steam generator 4 x 900 W
Effect, jacket HS33 60-liters: 1 000 W HS33 100-liters: 1 400 W
Frequency
50/60 Hz
(depending on power supply option)
Air supply 5-7 bar dry, fi ltered to 5 microns
Heat emission: closed door / open door Approx. 615 W / approx. 1 300 W
Noise level <73 dB
Air fi lter 0,2 µm
Weight (with water-fi lled chamber)
HS33 60-liters: 310 kg (373 kg)
HS33 100-liters: 355 kg (454 kg)
Weight/cm
2
HS33 60-liters: 12,5 kg/cm
2
HS33 100-liters: 16 kg/cm
2
Installation, max. altitude 2000 m above sea level
Minimum period of time that printed records
remain legible
12 years, under following storgae conditions:
- temperature up to 60°C
- humidity up to 90% in 40°C
- light exposure up to 10000kJ/m
2
Minimum light intensity in the room where the
sterilizer will work/ appropriate lighting
200lx / 350lx
Documentation
Thermal printer connected to independent documentation
system with separate pressure and temperature sensors
