OPERATING STATUS DISPLAY
Report Description Measure to solve the problem
Safety open limit operated
Turn mains supply OFF and move the shutter down-
wards - with the manual operator- until the safety limit
is free or the open limit should be re-adjusted
Safety close limit operated
Turn mains supply OFF and move the shutter upwards
- with the manual operator- until the safety limit is free
or the close limit should be re-adjusted
Door load monitor has
activated
Check the door mechanism for tightness
Limits not adjusted
Adjust limits
Entrapment safety device
actuated
Check all connected sensors (e.g. re-adjust photo
–beam)
Entrapment safety device
defective
Check all connected sensors
Safety edge 8k2 defect
Safety edge 1k2 activated
Check safety edge and connecting cable are not
broken
Safety edge 1k2 defect Check safety edge and connecting cable do not have
a short circuit
Safety edge 1k2 pneumatic
system TESTING negative
Check the proper safety edge function and that testing
in the lower door position is correct
Optical safety edge activated
or defect
Check the proper safety edge function or whether the
supply cable is interrupted
Check safety edge and connecting cable are not
broken
Door safety switch: function
Crash detector interrupted
X2.1-X2.2
Check the switch is proper tted or activated. After
fault repair: Press STOP-button for a minimum of 3 s
Light curtain defective
Read the light curtain manufacturer specication
instructions. Check connection cable
Light curtain actuated at
terminals X2.3 - X2.5 /
X6.1 - X6.2
Check light curtain
Check the connection cable is in order
