MDE-5222F
44
SECTION 4 - INSTALLATION
4
For detailed block diagrams of cable connections, refer to Appendix B: Block Diagrams” on page 53.
Figure 27 on page 43 shows an example of good cable routing (cables secured with cable clamps and
cable- ties).
Figure 28: Example of Door Installation
Speaker connections
are bypassing PIP3
and are routed to the
intercom interface
board.
Cables routed over card reader to prevent getting caught.
TRIND option
shown. Note that
wires must stay on
this side of metal
shield.
For start-up and configuration instructions for FlexPay IV CRIND, refer to MDE-5221 FlexPay IV CRIND
Start-up Manual.
