SECTION 4 - INSTALLATION
4
MDE-5222F
The ground cables from the UPM, card reader, and printer should ideally be connected to the chassis as
shown in Figure 27 (i). However, for some CRIND door configurations, the cables will not reach the position
shown, and in that case, the ground cables must connect to chassis as shown in Figure 27 (iii).
Figure 27: Ground Wire Connected to Chassis
(i)
(ii)
Ground Wire Connections
(iii)
