57
SECTION 6 - APPENDICES
6
MDE-5222F
Dedicated High-Speed Field Wiring (Non-POS) Instructions (DCM2.2
only)
MOC
If you are using the dedicated high-speed connection (MOC configuration), refer to the following:
Figure 9: Block Diagram for DCM2.2 Two-wire Configuration (Dedicated)
The following table lists wiring details for MOC mode:
Cable Part Connector Color Description
M02993A006 P333.1 Yellow High Speed
M02993A006 P333.2 Yellow High Speed
M02993A006 P333.3 Red CRIND+
M02993A006 P333.4 Blue CRIND-
