GILBARCO VEEDER-ROOT FlexPay IV CRIND User Manual

MDE-5222F
58
SECTION 6 - APPENDICES
6
Generic
If you are using the dedicated high-speed connection (Generic type configuration), refer to the following:
Connect the M02993A006 Dedicated High-Speed Cable (M02993A006) from P333 on DCM2.2 to the
dedicated high-speed connection from the back room as shown in Figure 9 on page 57.
The following table lists wiring details for Generic mode:
Cable Part Connector Color Description
M02993A005 P300.1 Red CRIND+
M02993A005 P300.3 Yellow CRIND-
M02993A006 P333.1 Yellow High Speed
M02993A006 P333.2 Yellow High Speed
M02993A006 P333.3 Red Pump+
M02993A006 P333.4 Blue Pump-
