GILES FSH-2-PH - Hood Clearances; Fire Suppression System

The fire suppression system installed in the Giles ventless hood is an ANSUL® R‐102 Restaurant Fire Suppression
System (UL‐710B Listed). Final field set‐up, charging, certification and arming of the system must be performed
by an authorized Ansul distributor/dealer in accordance with the system listing.
The fire suppression system is designed and ULlisted to provide fire protection for the fryer. It is a mechanically
activated system that protects continuously. This factoryinstalled system is selfcontained and includes all piping,
nozzles (appliance & plenum), Automan release mechanism, detector link brackets, conduit for link cable, exhaust
outlet fire damper and a 11/2 gal. stainless steel wet chemical suppressant storage tank.
.
Field setup by an Ansul agent shall include, but may not be limited to, installation of proper fusible detector links
and cable, filling & installing the provided suppressant storage tank, installing a remote manual activation station,
installing a compressed gas firing cartridge, testing, certifying and arming the system. Necessary parts and labor
for system field set‐up is the responsibility of the customer and is not included with hood purchase.
2.05 Fire Suppression System
12
Installation
FSH−2−PH
.XXX = ±.020
SHEET METAL DEPT.
DECIMALS
ANGULAR ± 2°
DECIMALS
MACHINE SHOP
.XX = ±.010
.XX = ±.031
TITLE:
MONTGOMERY, ALABAMA
RESTRICTED CO
N
THIS DRAWING AND ALL THE INFORM
A
EXCLUSIVE PROPERTY OF GILES EN
TE
ON A CONFIDENTIAL BASIS. THE REC
IP
DRAWING, TO RETURN IT UPON REQ
UE
DRAWING OR THE INFORMATION SH
OW
PARTY WITHOUT THE PRIOR WRITTE
N
REF, 3 VIE
W
FSH-2
SUBJECT/MODEL:
ENTERPRISES, INC.
SYM.
REVISIONS
DESCRIPTION
60A RECEPT.
NEMA 15-60R
(SUPPLIED WITH
3 PH ONLY)
APPLIANCE
STAND OFF
IN HOOD
26 7/8
683
24 3/8
619
20 1/4
515
INSIDE
22 3/16
564
24 1/8
613
67 1/8 1705
31 7/16
799
30 15/16
787
28 1/8
714
3
76
38 1/16 967
46 1/8 1172
FIRE EXTING
MANUAL PULL
CONNECTION
HOOD AND APPLIANCE
INTERLOCK CONNECTION
( 1 PHASE ONLY)
POWER CONNECTION
(HOOD ONLY 1PHASE)
(HOOD AND APPLIANCE 3 PH
)
85 7/16 2170
7'-2 7/16" 2195
MIN. TO CEILING
AIR FLOW
C CHANGE TO LOW PROFILE DIVERTER
B CHANGED TO 3-WAY AIR DIVERTER
A RELEASE FOR PRODUCTION
FIRE ALARM TIE-IN BOX
INCHES [mm]
2.04.2 Hood Clearances
SIDEFRONT BACK
