Overview
FSH-2-PH
* Not present on HEPA Filter Models
Item Description Function
1
E.A.C. Filter Status
Indicators
[ON]
[WASH]
[CHECK]
LED light cluster indicates status of the Electronic Air Cleaner (E.A.C.)
system.
[ON] Turns ON when hood is poweredup. Indicates that the E.A.C.
system is powered and functioning normally to clean the air. This is the
only light ON when system is operating normally.
[WASH] Indicates excessive grease film buildup on collector fins
(dirty), collector cell is missing, poor connection, missing ionizer wires,
etc. Approximately 2 minutes after this light turns ON, a beeping alarm
tone sounds and power to fryer is shutdown.
IMPORTANT! Do not rely on this indicator as a signal for routine
cleaning; cell must be cleaned daily to maintain peak performance and
extend useful life of charcoal filters.
[CHECK] Indicates that collector cell has stopped operating properly; it
is damaged
& shorted to ground, fins are shorted due to excessive
moisture, etc. No alarm sounds
& the fryer remains powered, but air is
not being cleaned by the EAC. Discontinue operation & inspect.
2 HOOD POWER Indicates that hood is powered and running.
3 FRYER POWER Indicates that power is being supplied to the fryer under the hood.
4 FILTER MISSING
Indicates that baffle and/or charcoal filter is missing or improperly
installed.
5
Power Switch
PUSH‐TO‐START
Turns hood power ON and OFF. When hood fan reaches the proper
speed, power is supplied to the fryer. To start hood, press &
momentarily hold the top START portion of the switch; release when fan
starts ... the switch springs back to remain ON. Hood must be restarted
in this manner after any lost of power.
*
6 CHANGE SOON
Illuminates when the EAC Cleaning Timer enters [WARNING] mode.
Indicates that the cell needs to be cleaned (or exchanged with a clean
standby) within the next 24 hours.
*
7 CHANGE NOW
Illuminates when the EAC Cleaning Timer enters [TIMEOUT] mode.
Allowed time between cleanings (or exchange) has expired. The cell
must immediately be cleaned (or exchanged). An audible alarm
sounds and both hood & fryer are locked out, preventing continued
operation until the appropriate activities are performed.
*
8 SNOOZE
Pressing this button delays [TIMEOUT] mode for 2 hours, allowing the
hood & fryer to continue to operate for finishing a cook cycle or
meeting customer demand. Two (2) snooze cycles are allowed before
the shutdown process continues.
