GILGEN SLX - Locking;Manual Unlocking

SLX
0635-999-05---08p_2017.12.indd



KABA 1514 –
SEA 1.043.0 –
DOM 2222Hix-5 333Hix-5
ZEISS-IKON – 0040
– 5040
– 5532 (L = 40 mm)
KESO 11.014.045 21.214.040
21.014.145 –
31.014.045 –
BKS – 3101 NBL31
– 3301 NBL31
– 8900 NBL31
0635-999/06p
Page 11 of 30
Operator manual
3.3.6 Locking/Manual unlocking
In the event of an emergency or of a mains
failure (without the option emergency
battery), the closed door can be opened
by pulling the red manual unlocking resp.
remote manual unlocking while at the same
time pushing the sliding wings to the open
position.
If the door leads to a room without a second
access, a lockable remote manual unlocking
is mounted on the outside of the door.
Warning:
The manual unlocking mecha-
nisms must be easily visible and
accessible at all times.
Manual unlocking
internal
Lockable remote manual
unlocking
Remote ma-
nual unlok-
king
Thecylindermustbeequippedwithareversibledriver8x45°.
Cylinder type
