Operator manual
3 PRODUCT DESCRIPTION
3.1 General remarks
The door drive mechanism SLX allows an automatic opening and closing of sliding doors.
The operating characteristics of the door can be determined via a control element (selec-
tion of the operating modes and setting of their respective parameters).
A sliding door installation may consist of the elements designated hereafter:
A Door drive mechanism F Push-button*
B Manual unlocking* G D- or C-BEDIX* Control element
C Side panel* H BEDiX* Control element
D Sliding wing I COMBI-SCAN INT Detector
E Key-operated pivoting switch* J COMBI-SCAN EXT Detector
* Option
