Rear Anti Roll Bar Adjustment
• There are 6 settings for the RARB
• To adjust hole position:
• Remove 2 x M6 bolts from drop links
• Move drop link to new position
• Replace bolt in new position
• Torque to 18Nm (5mm hex key + 7mm spanner)
• Disconnect 1 drop link during set up
• Reconnect when set up completed
• If required adjust drop link length to remove all preload
Hole position Wheel Rate
Top 1 58 N/mm
2 71 N/mm
Mid 3 89 N/mm
4 114 N/mm
5 170 N/mm
Bottom 6 206 N/mm
Hole Settings
