Chassis Loom Supported Accessories:
• There are several accessories supported by the chassis loom
• All of which are customer supplied, installed and configured
• Refer to table on right for Pin outs
General Layout:
Balloon Number Part Description
1 Alternator
2 Battery
3 Battery Isolator
4 Dashboard
5 ECU
6 EPAS
7 EPAS ECU
8 E-Shift
9 External Kill Switch
10 Power Distribution Module
11 Starter Motor
12 Wiper Motor
