Ginlong Solis 5G Series User Manual

User Manual
36
7.2.1 Lock Screen
Pressing the ESC key returns to the Main Menu. Pressing the ENTER key locks
(Figure 7.2(a)) or unlocks (Figure 7.2 (b)) the screen.
(b)Unlock(a) Lock
Figure 7.2 Locks and Unlocks the Screen of LCD
Display
Duration
Description
Work Mode: Volt-watt
DRM NO.:08
5 sec
Work Mode: Shows current working mode.
DRM NO.: Shows DRM Number.
I_DC01: +00.0A
I_DC02: +00.0A
.. .
I_DC28: +00.0A
Table 7.2 Information list
5 sec
I_DC01 : Shows string 01 current value.
I_DC02 : Shows string 02 current value.
...
I_DC28 : Shows string 28 current value.
V_DC01: +0000.0V
I_DC02: +00.00A
.. .
V_DC14: +0000.0V
I_DC14: +00.00A
5 sec
V_DC01 : Shows MPPT 01 voltage value.
I_DC01 : Shows MPPT 01 current value.
...
V_DC14 : Shows MPPT 14 voltage value.
I_DC14 : Shows MPPT 14 current value.
7. Normal operation
