User Manual
63
8.2 Fan Maintenance
5. Remove the 2 screws on the fan plate.
6. Pull out the fan module slowly and unplug the power plug of the fan after pulling out
around 150mm.
7. Clean and replace the broken fan.
8.Connect the electrical wire and reinstall the fan. Restart the inverter.
NOTE
If you need to maintain the inverter at night, please turn off the AC switch first,
then turn off the DC switch, and wait 20 minutes before you do other operations.
Figure 8.2
8. Maintenance
If the fan doesn’t work properly, the inverter will not be cooled effectively and it may affect
the operation of the inverter.
Instructions below describe the necessary steps to replace a damaged or broken fan.
1. Turn off the “Grid ON/OFF switch on the inverter LCD.
2. Disconnect the AC power.
3. Turn the DC switches to “OFF” position
4.Wait for at least 15 minutes.
To Next Page
