GME CP30 - Dynamic Volume Control; Audio Boost

31
CP30 INSTRUCTION MANUAL
Dynamic Volume Control
The modulation levels of signals heard on the UHF CB band may vary considerably
resulting in noticeable dierences in received audio volume between stations. This
is particularly apparent now that both wide and narrowband transmissions are
sharing channels 1-40. Generally users have compensated for these dierences by
adjusting the volume control for each incoming signal.
The CP30 has a unique GME feature called Dynamic Volume Control (DVC) that
automatically compensates for these variations in received audio level. When
activated, this feature automatically adjusts the received audio level resulting in a
constant audio output level to the speaker.
To Enable Dynamic Volume Control
1. Hold the
MENU
F
key to access the menu. The last selected menu item
will be displayed.
2. Rotate the Channel Selector knob or press the keys until
DYNVOL is displayed.
3. Press the
MENU
F
key.
4. Rotate the Channel Selector knob or press the keys to select
ON or OFF.
5. When the desired setting is displayed, press the
MENU
F
key to exit the
menu or wait a few seconds for the menu to time-out.
Audio Boost
Audio Boost enhances and provides additional gain to the received audio volume
output when using an external speaker microphone such as the MC012 (IP67
Remote Speaker Microphone).
LO: Nominal Gain
MEDIUM: + 6dB
HI: + 12dB
To Adjust the Audio Boost Level:
1. Hold the
MENU
F
key to access the menu. The last selected menu item
will be displayed.
2. Rotate the Channel Selector knob or press the keys until
AUDBST is displayed.
3. Press the
MENU
F
key AUD is displayed.
