CP30 INSTRUCTION MANUAL
94
CP30 SPECIFICATIONS (CONT.)
RECEIVER
Sensitivity: -120 dBm for 12 dB SINAD
Intermediate Frequencies: 1st: 38.85 MHz 2nd: 450 kHz
Adjacent Channel Selectivity:
> 60 dB (NB)
> 70 dB (WB)
Spurious Response Immunity: > 70 dB
Audio Output Power: 1.5 W (8Ω)
Audio Signal to Noise: 34 dB (SINAD)
TRANSMITTER
RF Output:
High: 5 W
Low: 1 W
Ultra-Low: 100 mW
Frequency Stability: ± 2.5 PPM
Modulation: FM
Spurious Emission: < -34 dBm
Adjacent Channel Power: < -67 dBm
Maximum Deviation: ± 2.5 kHz
Audio Harmonic Distortion: 0.4% @ 1kHz / 1.5kHz Deviation
