16 DDV9550 USER’S GUIDE
Front Panel Inputs
Copy Tape
Menu
TV/VCR Video L Audio RChannel
Hi-Fi
Deck
V
9550
Audio Left Input — (White) Use
to connect the left audio signal
from your external device with
an RCA cable. Connect monau-
ral (mono) audio sources here.
Video Line Input — (Yellow)
Use to connect the video
signal from your external
device with an RCA cable.
Audio Right Input — (Red) Use
to connect the right audio signal
from your external device with
an RCA cable.
Use the Front Panel Inputs for
easy connection to a camcorder
or video game. The front panel
inputs are referred to as Aux
throughout the menu system.
