Goodwe GW10K-ET User Manual

7
03 Product IntroductionUser Manual V1.1-2022-12-20
3 Product Introduction
Inverters control and optimize the power in the PV system through an integrated energy
management system. The power generated in the PV system can power the loads, stored in the
battery, output to the utility grid, etc.
Intended usage
3.1 Product Overview
Model
Model
This manual applies to the listed inverters below:
ET Series (Hybrid Inverter)
BT Series (AC-Coupled Inverter)
No. Referring to
1 Brand Code GW: GoodWe
2 Rated Power • 5K: the rated power is 5kW.
• 6K: the rated power is 6kW.
• 6.5K: the rated power is 6.5kW.
• 8K: the rated power is 8kW.
• 10K: the rated power is 10kW.
3 Product Feature • L: lower voltage
• N: higher PV input current
4 Series Code • ET: ET series hybrid inverter
• BT: BT series AC-Coupled inverter
• GW5KL-ET
• GW6KL-ET
• GW8KL-ET
• GW10KL-ET
• GW5K-ET
• GW6.5K-ET
• GW8K-ET
• GW10K-ET
• GW5KN-ET
• GW6.5KN-ET
• GW8KN-ET
• GW10KN-ET
• GW5K-BT
• GW6K-BT
• GW8K-BT
• GW10K-BT

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
