Goodwe GW10K-ET User Manual

49
08 System Commissioning
User Manual V1.1-2022-12-20
8.2 Setting Inverter Parameters via SolarGo App
8.3 Monitoring via SEMS Portal
SEMS Portal is an monitoring platform used to communicate with the inverter via WiFi, LAN, 4G
or GPRS. Commonly used functions:
1. Manage the organization or User information;
2. Add and monitor the power plant information;
3. Equipment maintenance.
NOTICE
Please set the inverter parameters rst via SolarGo app to ensure its operation.
SEMS Portal
SolarGo app is a smart phone application used to communicate with the inverter via bluetooth,
WiFi, 4G or GPRS modules. Commonly used functions are as follows:
1. Check the operating data, software version, alarms, etc.
2. Set grid parameters, communication parameters, etc.
3. Equipment maintenance.
4. Upgrade software version.
For more details, refer to SolarGo User Manual. Scan the QR code or visit https://en.goodwe.
com/Ftp/EN/Downloads/User%20Manual/GW_SolarGo_User%20Manual-EN.pdf to get the user
manual.
SolarGo App
SolarGo App User Manual

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
