Goodwe GW10K-ET User Manual

25
05 InstallationUser Manual V1.1-2022-12-20
CAUTION
• Operations such as transportation, shipment, installation and so on shall in compliance with
laws and regulations of the country or region where the inverter is located.
• Move the inverter to the site before installation. Follow the instructions below to avoid
personal injury or equipment damage.
1. Consider the weight of the equipment before moving it. Assign enough personnel to
move the equipment to avoid personal injury.
2. Wear safety gloves to avoid personal injury.
3. Keep balance to avoid falling down when moving the equipment.
5.2 Inverter Installation
5.2.2 Installing the Inverter
5.2.1 Moving the Inverter
NOTICE
• Avoid the water pipes and cables buried in the wall when drilling holes.
• Wear goggles and a dust mask to prevent the dust from being inhaled or contacting eyes
when drilling holes.
• The DC switch lock of appropriate size should be prepared by customers. Diameter of the
lock hole is φ8mm. Choose the appropriate size. Otherwise, it might not be able to install.
Only for hybrid inverters.
• The anti-theft lock of appropriate size should be prepared by customers. Diameter of the
lock hole is 10mm.
• Make sure the inverter is rmly installed in case of falling down.
Step 1 Put the plate on the wall horizontally and mark positions for drilling holes.
Step 2 Drill holes to a depth of 80mm using the hammer drill. The diameter of the drill bit should
be 10mm.
Step 3 Secure the mounting plate using the expansion bolts.
Step 4 (Optional) Secure the DC switch with the DC switch lock, ensuring that the DC switch is
"OFF" during installation.
Step 5 Install the inverter on the mounting plate.
Step 6 Tighten the nuts to secure the mounting plate and the inverter.

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
