Goodwe GW10K-ET User Manual

16
03 Product Introduction User Manual V1.1-2022-12-20
Communication module like Bluetooth, 4G, WiFi, and LAN is supported.
The inverter supports parameter setting in a short distance. Connecting to the server via 4G,
WiFi, or LAN to monitor the working status of the inverter and the running situations of the
power plant, etc.
• Bluetooth: meets Bluetooth 5.1 standard
• 4G (optional): supports mainstream telecommunication operators like AT&T and T-Mobile.
• WiFi: supports 2.4GHz frequency band. Set the router to 2.4GHz or 2.4GHz/5GHz coexistence
mode. The maximum length of a WiFi network name is 40 bytes.
• LAN (optional): connects the inverter to the router via LAN communication and then to the
server.
Communication

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
