40
06 Electrical Connection User Manual V1.1-2022-12-20
NOTICE
Do not remove the resistor or short circuit wire unless you are going to use DRED or RCR.
Enable the DRED function or remote shutdown function via SolarGo app after cable
connections.
Example:
2
4
1
5
3
6~8mm
0.12~0.8mm
2
1
2
DI 1
(PIN 7
PIN 8
PIN 6
PIN 5
PIN 4
PIN 3
K 1
K 2
K 3
K 4
100%
60%
30%
0%
DI 3
REF_2
REF_1)
DI 2
DI 4
RS485
1
2
1.5N·m
1
3
2
4
5
3-1
4-1
10
8
7
9

Other manuals for Goodwe GW10K-ET

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Goodwe GW10K-ET and is the answer not in the manual?

Goodwe GW10K-ET Specifications

General IconGeneral
ModelGW10K-ET
Max. DC Input Voltage1000 V
Number of MPPTs2
Rated AC Output Power10000 W
Max. AC Output Power11000 VA
Frequency50 Hz / 60 Hz
Efficiency98.3%
Dimensions516 x 415 x 180 mm
Weight25 kg
Max. DC Input Power13000 W
Start Voltage180 V
MPPT Voltage Range200V - 1000V
Number of MPP Trackers2
Max. Short Circuit Current per MPPT15 A
Nominal AC Output Power10000 W
Max. AC Apparent Power11000 VA
Nominal AC Voltage230 V / 400 V
Nominal Grid Frequency50 Hz / 60 Hz
THDi<3%
DC SwitchYes
Protection ClassIP65
Operating Temperature Range-25°C to +60°C
Cooling MethodNatural Convection
Rated Output Power10000 W
Grid Frequency50 Hz / 60 Hz
Max. Efficiency98.3%
Noise Level<30 dB
Protection DegreeIP65
TypeThree Phase
AC Voltage Range180V - 280V
Power Factor0.8 leading - 0.8 lagging
Rated Grid Voltage230 V
