Goodwe GW10K-ET User Manual

52
09 Maintenance User Manual V1.1-2022-12-20
No. Fault Cause Solutions
3
Grid Rapid
Overvoltage
The grid voltage is
abnormal or ultra-
high.
1. If the problem occurs occasionally, the
utility grid may be abnormal temporarily.
The inverter will recover automatically
after detecting that the utility grid is
normal.
2. Check whether the high grid voltage
continues for a long time. If the problem
occurs frequently, check whether the grid
voltage is within the allowed range.
• Contact the local power company if the
grid voltage exceeds the permissible
range.
• Modify the grid overvoltage rapid
protection threshold after obtaining
the consent of the local power
company if the grid voltage is within
the permissible range.
4
Grid
Undervoltage
The grid voltage
is lower than the
permissible range,
or the duration of
low voltage exceeds
the requirement of
LVRT.
1. If the problem occurs occasionally, the
utility grid may be abnormal temporarily.
The inverter will recover automatically
after detecting that the utility grid is
normal.
2. If the problem occurs frequently, check
whether the grid voltage is within the
permissible range.
• Contact the local power company if the
grid voltage exceeds the permissible
range.
• Modify the undervoltage protection
threshold, LVRT or disable the
undervoltage protection function after
obtaining the consent of the local
power company if the grid frequency is
within the permissible range.
3. Check whether the AC circuit breaker and
the output cables are connected securely
and correctly if the problem persists.

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
