Goodwe GW10K-ET User Manual

62
10 Technical Parameters User Manual V1.1-2022-12-20
Technical Parameters GW5KL-ET GW6KL-ET GW8KL-ET GW10KL-ET
Nominal Output Voltage (V)
400/380,
3L/N/PE
400/380,
3L/N/PE
400/380,
3L/N/PE
400/380,
3L/N/PE
Nominal AC Grid Frequency (Hz) 50/60 50/60 50/60 50/60
Max. AC Current Output to Utility
Grid (A)
8.5 10.5 13.5 16.5
Max. AC Current From Utility Grid (A) 15.2 18.2 22.7 22.7
Nominal Output Current (A) 7.5 9 12 14.5
Power Factor ~1 (Adjustable from 0.8 leading to 0.8 lagging)
Max. Total Harmonic Distortion <3% <3% <3% <3%
AC Output Data (Back-up)
Back-up Nominal Apparent Power
(VA)
5,000 6,000 8,000 10,000
Max. Output Apparent Power (VA)
*3
5,000
(10,000
@60sec)
6,000
(12,000
@60sec)
8,000
(16,000
@60sec)
10,000
(16,500
@60sec)
Max. Output Current (A) 8.5 10.5 13.5 16.5
Nominal Output Voltage (V) 400/380 400/380 400/380 400/380
Nominal Output Frequency (Hz) 50/60 50/60 50/60 50/60
Output THDv (@Linear Load) <3% <3% <3% <3%
Eciency
Max. Eciency 98.5% 98.5% 98.5% 98.5%
Max. Battery to AC Eciency 98.5% 98.5% 98.5% 98.5%
Protection
PV Insulation Resistance Detection Integrated Integrated Integrated Integrated
Residual Current Monitoring Integrated Integrated Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated Integrated Integrated
Anti-islanding Protection Integrated Integrated Integrated Integrated
AC Overcurrent Protection Integrated Integrated Integrated Integrated
AC Short Circuit Protection Integrated Integrated Integrated Integrated
AC Overvoltage Protection Integrated Integrated Integrated Integrated
DC Switch Optional Optional Optional Optional
DC Surge Protection Type III Type III Type III Type III
AC Surge Protection Type III Type III Type III Type III

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
