Goodwe GW10K-ET User Manual

74
10 Technical Parameters User Manual V1.1-2022-12-20
Technical Parameters GW5K-BT GW6K-BT GW8K-BT GW10K-BT
Nominal Output Voltage (V) 400/380 400/380 400/380 400/380
Nominal Output Frequency (Hz) 50/60 50/60 50/60 50/60
Output THDv (@Linear Load) <3% <3% <3% <3%
Eciency
Max. Eciency 97.60% 97.60% 97.60% 97.60%
Max. Battery to AC Eciency 97.6% 97.6% 97.6% 97.6%
Protection
PV Insulation Resistance Detection Integrated Integrated Integrated Integrated
Residual Current Monitoring Integrated Integrated Integrated Integrated
PV Reverse Polarity Protection Integrated Integrated Integrated Integrated
Anti-islanding Protection Integrated Integrated Integrated Integrated
AC Overcurrent Protection Integrated Integrated Integrated Integrated
AC Short Circuit Protection Integrated Integrated Integrated Integrated
AC Overvoltage Protection Integrated Integrated Integrated Integrated
DC Switch Integrated Integrated Integrated Integrated
DC Surge Protection Type III Type III Type III Type III
AC Surge Protection Type III Type III Type III Type III
General Data
Operating Temperature Range (℃) -35 ~ +60 -35 ~ +60 -35 ~ +60 -35 ~ +60
Relative Humidity 0~95% 0~95% 0~95% 0~95%
Max. Operating Altitude (m) 4000 4000 4000 4000
Cooling Method Natural Convection
User Interface LED, APP LED, APP LED, APP LED, APP
Communication with BMS
*3
RS485, CAN RS485, CAN RS485, CAN RS485, CAN
Communication with Meter RS485 RS485 RS485 RS485
Communication with Portal WiFi, LAN WiFi, LAN WiFi, LAN WiFi, LAN
Weight (kg) 21 21 21 21
Noise Emission (dB) <30 <30 <30 <30
Topology Non-isolated
Self-consumption at Night (W)
*4
<15 <15 <15 <15

Goodwe GW10K-ET Specifications

General

Model	GW10K-ET
Max. DC Input Voltage	1000 V
Number of MPPTs	2
Rated AC Output Power	10000 W
Max. AC Output Power	11000 VA
Frequency	50 Hz / 60 Hz
Efficiency	98.3%
Dimensions	516 x 415 x 180 mm
Weight	25 kg
Max. DC Input Power	13000 W
Start Voltage	180 V
MPPT Voltage Range	200V - 1000V
Number of MPP Trackers	2
Max. Short Circuit Current per MPPT	15 A
Nominal AC Output Power	10000 W
Max. AC Apparent Power	11000 VA
Nominal AC Voltage	230 V / 400 V
Nominal Grid Frequency	50 Hz / 60 Hz
THDi	<3%
DC Switch	Yes
Protection Class	IP65
Operating Temperature Range	-25°C to +60°C
Cooling Method	Natural Convection
Rated Output Power	10000 W
Grid Frequency	50 Hz / 60 Hz
Max. Efficiency	98.3%
Noise Level	<30 dB
Protection Degree	IP65
Type	Three Phase
AC Voltage Range	180V - 280V
Power Factor	0.8 leading - 0.8 lagging
Rated Grid Voltage	230 V
