1. Remove the piece of foam covering the bottom of the machine.
4
Foam
1. Identify which wheel assembly is for the front and which is for the back.
5
1. Attach the front wheel assembly to the bottom of the machine with the two M6 shoulder bolts
and the 4 mm Allen wrench. Make sure the holes in the back of the wheel assembly are facing
towards the back.
6
Shoulder Bolts M6 (x2)
Holes
Task 2 - Installing the Wheels (continued)
Part Two | Out of Box Assembly
Front Wheel Assembly:
• No visible screws on top
• One rubber spacer
Back Wheel Assembly:
• Visible screws on top
• Two metal spacers
To Next Page
